Sound Devices 833 8-Channel / 12-Track Multitrack Field Recorder

http://localhost:8069/web/image/product.template/872/image_1920?unique=a86786c

Key Features
Location Recording and Filmmaking
Per-Channel EQ, HPF, Limiting & More
6 x High-Gain, Low-Noise Mic Preamps
Records 8 Inputs & 4 Buses
Up to 8 Channels of Dugan Automixing
Supports External Remote Control
DC & Dual L-Series Battery Powering
Internal 256GB SSD & Dual SD Card Slots
I/O for Timecode or Word Clock

This product is no longer available.

Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days

We DELIVER COUNTRYWide

bEST PRICES IN TOWN

100% Secured
Payment

07-Day Return
Policy

Sound Devices 833 8-Channel / 12-Track Multitrack Field Recorder
Sound Devices XL-WPTA4 AC to DC Power Supply for Scorpio Mixer-Recorder
LCD Cover
SMA Antenna
Promo Sticker (White)
Promo Sticker (Black)
48 x Dots: Red, Yellow, Blue, Green, Purple, White (8 per Color)
Limited 1-Year Manufacturer Warranty

Sound Devices 833 Specs

Portable Recorder

Number of TracksWAV:
12
Maximum Sampling Rate192 kHz / 32-Bit
MicrophoneBuilt-In Slate Mic
Built-In SpeakerNo
DisplayColor LCD Touchscreen
Memory Card SupportSD, SDHC
Internal Storage256 GB

Recording

Audio File FormatsBWF, WAV
Sample RatesWAV:
44.1 / 47.952 / 48 / 48.048 / 88.2 / 96 / 192 kHz
Bit Depth32-Bit (A/D Conversion)
16 / 24-Bit (Recording)
Signal Processing & FXAuto Gain, Delay, EQ, Limiter, Low-Cut Filter, Output Limiting
Timecode SupportYes
Frame Rates Supported23.976 / 24 / 25 / 29.97 / 29.97 DF / 30 / 30 DF
Clock Accuracy0.1 ppm / 0.25 Frame per 24 Hrs (Timecode)
Recording TimeWAV 44.1 kHz/24-Bit:
10.5 Mins per GB (All Channels)
WAV 48 kHz/24-Bit:
9.6 Mins per GB (All Channels)
WAV 96 kHz/24-Bit:
4.8 Mins per GB (All Channels)
WAV 192 kHz/24-Bit:
2.4 Mins per GB (All Channels)

Connectivity

Analog I/O3 x XLR 3-Pin Female Balanced Line/Mic Input (Lockable)
3 x TA3 3-Pin Male Active-Balanced Line/Mic Input (Lockable)
1 x 1/8" / 3.5 mm TRS Female Unbalanced Aux Input
1 x TA3 3-Pin Male Balanced Com Return Input (Lockable)
1 x TA5 5-Pin Male Unbalanced Headphone/Mic In/Out (Lockable)
1 x 1/4" TRS Female Unbalanced Headphone Output
1 x 1/8" / 3.5 mm TRS Female Unbalanced Headphone Output
2 x XLR 3-Pin Male Active-Balanced Instrument/Line/Mic Output (Lockable)
2 x TA3 3-Pin Male Active-Balanced Instrument/Line/Mic Output (Lockable)
1 x 1/8" / 3.5 mm TRS Female Unbalanced Line Output
Digital I/O1 x LEMO 5-Pin Timecode/Word Clock In/Out
1 x RP-SMA Antenna Input
1 x XLR 3-Pin AES3 / AES42 Input
2 x XLR 3-Pin AES3 Output
Phantom Power+12 / 48 V (Selectable on Individual Inputs)
Phantom Power Current10 mA per Channel
System Connection1 x USB-C (3.0 / 3.1/3.2 Gen 1)
1 x USB-A (Control, Text Entry)

Performance

Frequency Response10 Hz to 80 kHz ±0.5 dB (at 192 kHz)
Gain/Trim RangeMic Inputs:
Up to +76 dB
Line Inputs:
Up to +50 dB
Fader:
Up to +16 dB
Headphone Outputs:
Up to +20 dB
Max Input LevelMic Inputs:
+8 dBu
Line Inputs:
+28 dBu
Aux Inputs:
+18 dBu
Com Return Input:
+24 dBu
Slate Mic Input:
+12 dBu
Max Output LevelLine Outputs:
+20 dBu
TA3 Outputs:
+6 dBu
Headphone Outputs:
+14 dBu
Headphone Output Power400 mW per Channel
ImpedanceMic/Line Inputs:
4 Kilohms
Aux Inputs:
4 Kilohms
Com Return Input:
8 Kilohms
Slate Mic Input:
8 Kilohms
Balanced Outputs:
250 Ohms (Mic Level)
120 Ohms (Line Level)
3.2 Kilohms (-10 dBV)
Unbalanced Outputs:
1.8 Kilohms
Headphone Outputs:
4 Ohms
THD+N0.005%
EIN-129 dBu (A-Weighted)

Power

Power OptionsBattery, AC/DC Power Adapter
Battery Type2 x L Series (Not Included)
AC/DC Power Adapter10 to 18 VDC (Included)

Physical

Mounting Options1/4"-20 Female (Bottom)
Operating Temperature-4 to 140°F / -20 to 60°C
Storage Temperature-40 to 185°F / -40 to 85°C
Operating Humidity0 to 90%
Dimensions8.7 x 2 x 6.7" / 22 x 5.1 x 17 cm
Weight2.8 lb / 1.3 kg (without Batteries)

Packaging Info

Package Weight5.61 lb
Box Dimensions (LxWxH)16 x 10.9 x 5.4"


Specifications

Brand Sound Devices
internal capacity 0
number of tracks 10
